For pure travel pleasure
We’re making it easy for you to choose the right HYMER: the semi-integrated Exsis-t Pure built on the Fiat Original frame is jam-packed with features, leaving nothing to be desired where comfort is concerned.
Lightweight construction techniques used throughout and the proven 140 hp Fiat drive in combination with the Fiat Original frame – ensuring you reach your destination without any difficulty. And all at an unbeatable price.
Configure the edition model to suit your requirements
Discover all of the design variants and optional accessories in our configurator. Design the HYMER Exsis-t Pure to perfectly suit your taste.To configurator
New chassis with the Fiat original frame
Experience pure travel pleasure on the proven 140 hp Fiat chassis in combination with the Fiat Original frame
Huge payload reserves
Thanks to the huge payload reserves of over 500 kg (including the PURE equipment package), you really can pack everything you need for your holiday
Including a reversing camera, air conditioning, cruise control, ambient lighting and a panoramic roof
One edition model, one price
Thanks to the attractive saving and comprehensive equipment package, which leaves nothing to be desired where comfort is concerned, we’re making it easy for you to choose the right HYMER vehicle. Benefit from a huge saving and embark on a journey of pure pleasure with the HYMER Exsis-t Pure.
Already made up your mind or still have some questions? Your HYMER partner will be only too happy to help.Your local dealer
Exsis-t 580 Pure
All technical data
Chassis Exsis-t 580 Pure Standard chassis Fiat Ducato low frame chassis Chassis at extra cost Fiat Ducato Maxi low frame Drive Front Wheel Drive Standard engine 2,2 Multijet kW (hp) 103 (140) Overall length, approx. cm 694 Body width, approx. cm 212 Overall width, approx. cm 222 Interior width, approx. cm 205 Overall height, approx. cm 277 Headroom in living area, approx. cm 198 Wheelbase, approx. mm 3800 Mass in running order, approx. kg 2993 Maximum load, approx. kg 507 Technically permissible total mass, kg 3500 Maximum permissible towing capacity, braked, kg 2000 Permitted number of persons 4 Insulation floor / side walls / roof, mm 41 / 34 / 34 Clearance of storage compartment / garage doors or flap, W x H, cm 85 x 109 / 65 x 65 Bed dimension: Rear bed, L x W, approx. cm 195 x 80 / 191 x 80 / 218 x 80 / 191 x 80 Berths 2 - 3 Bathroom, W x D, approx. cm 125 x 85 Wardrobe, W x D x H, approx. cm 27 x 54 x 160 Kitchen, W x D x H, approx. cm 90 x 60 x 93 Refrigerator volume incl. freezer, approx. l 142 Heating type Warm air, 6 kW / Warm air EH, 6 kW Gas supply, kg 11 / 11 Fresh water supply, approx. l 120 Water supply, approx. l (whilst driving) 20 Abwassertank (ca. l) 90 Additional habitation battery, Ah 95 Ah AGM #O# 50 Ah Lithium #O# 150 Ah Lithium #O# Sockets: 12 V 2 - 3 Sockets: 230 V 4 - 8 Sockets: USB 4 - 6
Chassis Fiat Ducato 3.5 t - 2.2 Multijet - 103 KW/140 hp - Euro VI-E Basis Exterior colors: White cab / White body Fiat Ducato low-frame chassis 6-speed transmission 90 l fuel tank 19 l AdBlue tank Electrically adjustable and heated exterior mirrors Mud flaps, rear axle Bumper painted in vehicle color LED Daytime Running Light integrated in headlights 16" alloy wheels with 225/75 R16 tires (Fiat Ducato Light only) 1x Twin USB socket in cab Dashboard tray instead of tablet holder Electric cab windows and central locking for cab Driver and passenger airbag Rear axle stabilizer Leather steering wheel and gear knob lever Manual AirCon with pollen filter Reinforced alternator incl. charging booster (up to 70 A) ABS (Anti-lock Brake System) / EBD (Electric Brake Force Distribution) ESP incl. ASR, Traction Plus and Hill Holder Post-collision brake control Crosswind Assist Start-Stop-System incl. intelligent alternator Fiat Cruise Control Body Awning with adapter, white or silver housing, 400 x 250 cm 60 cm Maxi habitation door Electric entrance step, 1-step Exclusive HYMER Multifunctional rear lights in LED-Hybrid technology External storage flap, 65 x 65 cm, LH side Garage load up to 350 kg (optional 450 kg). Please note the axle load. GRP lightweight floor with XPS insulation Large garage door, RH side Panoramic skylight above cab, manually hinged Optimal insulation thanks to the proven PUAL construction with foamed walls and roof (34 mm wall and roof thickness) and framed windows Premium high-tech construction aluminum / aluminum PUAL sandwich for optimal insulation (fully glued without cold bridges, 100% wood-free) Service flap for convenient access to the board electronics on the LH side Opening windows with blackout blind and mosquito net, LH and RH side, rear Window in habitation door incl. blackout blind and integrated waste bin Skylight (clear glass) above rear bed(s) with blackout blind and mosquito net, 40 x 40 cm Skylight (frosted glass) in bathroom with blackout blind and mosquito net, 40 x 40 cm Panoramic skylight in living room, double-glazed with LED-lighting, 80 x 50 cm Outfitting Cab seats, upholstered in living area fabric, height- and tilt adjustable, swivelling, with 2 armrests Cab blinds Mosquito net on habitation door Fabrics & Furniture finishes Furniture finish: Sauvignon Oak Fabric combination: Denver or Corfu Living and bedroom + lighting Bed conversion for comfort L-shaped seating group incl. additional cushion and lowerable table involving the cab seat Function integration into furniture elements Cold foam mattress incl. high-quality mattress pad (knitted fabric) for better ventilation in the rear Comfort L-shaped seating group with lounge cushions, longitudinal / transverse sliding table and 2 built-in 3-point belts Modern, linear interior design Additional cushion between the longitudinal single beds incl. integrated comfort access Ambient lighting Complete LED interior lighting LED worktop lighting LED awning light Kitchen Servo-Soft close in the kitchen Freely arrangeable kitchen drawers, extra wide 142 l Smart-Tower fridge Bathroom Wooden shower slats Installation & Technology 6 kW gas warm air heating with warm water boiler LCD keypad for heating incl. iNet ready Warm air heating in the rear bedroom, adjustable separately Automatic gas bottle changeover system with crash sensor and IceEx Gas filter for automatic gas bottle changeover Gas bottle compartment with access via the external flap / door Additional sockets: 4 x 230 V / 1 x 12 V / 1 x Twin-USB (incl. kitchen wall paneling) Reinforced battery, 12 V, 95 Ah AGM 120 l fresh water tank, insulated and heated (20 l in driving position) 90 l waste water tank, insulated and heated Multimedia Radio / TV pre-installation incl. 12 V and 230 V socket, 2 speakers in the cab as well as the alcove, radio and DVB-T2 antenna Reversing camera 32" TV bracket 32" LED-TV with built-in speakers, remote control, DVD drive, (DVB-T / C, DVB-S2) incl. receiver Digital satellite dish, 65 cm Packages
Chassis Fiat Ducato 3.5 t - 2.2 Multijet - 118 KW/160 hp - Euro VI-E Fiat Ducato 3.5 t - 2.2 Multijet - 130 KW/180 hp - Euro VI-E Fiat Ducato Maxi - 2.2 Multijet - 103 KW/140 hp - Euro VI-E Fiat Ducato Maxi - 2.2 Multijet - 118 KW/160 hp - Euro VI-E Fiat Ducato Maxi - 2.2 Multijet - 130 KW/180 hp - Euro VI-E Uprating to 3.65 t (Fiat Ducato 3.5 t Light only) Downplating to 3.5 t (Fiat Ducato Maxi only) Basis Exterior Cab color: Grigio Campovolo (Pastel) Exterior Cab color: Lanzarote gray (Pastel) Exterior Cab color: Alumino gray (Metallic) Exterior Cab color: Black (Metallic) Exterior Cab color: Artense gray (Metallic) Exterior Body color: Crystal-Silver Metallic incl. painted alcove 9-gear automatic transmission LED headlights Fog lights with cornering light Skid plate, glossy black 16" alloy wheels with 225/75 R16 tires (Fiat Ducato Maxi only or in combination with automatic transmission) 16" All-Season tires (with snowflake symbol) 16" steel spare wheel incl. bracket in the rear storage compartment Shelf for smartphones incl. wireless charging with charge level indicator Aluminium applications for ventilation nozzles Automatic AirCon with pollen filter Electric parking brake Multifunctional steering wheel Seat heating for cab seats, adjustable separately Fully digital cockpit with integrated 7" display Heated windscreen Driver Assistance System incl. Emergency Brake & Lane Keeping Assist, Traffic sign recognition, High Beam Assist as well as light and rain sensor Third ignition key with remote control (2nd key mechanical) Grill frame, glossy black Headlights with black frame Door handles painted in vehicle color Body Trailer hitch, detachable ball head (incl. pre-installation) Roof rack with rear ladder and checker plate roof panel GRP roof coating Comfort habitation door with window, blackout blind, integrated waste bin as well as 2-way lock Comfort jacks, rear (2 units) Frame extension incl. 450 kg garage load Security lock for habitation door Bicycle rack for 3 bicycles, max. load: 60 kg Bicycle rack for 4 bicycles, max. load: 60 kg Extendable motorcycle holder, can also be used for 2 bikes External insulation windscreen mat Electric roof vent with function supply and exhaust air at kitchen Panoramic skylight above rear bed(s), double-glazed with LED-lighting, 80 x 50 cm Outfitting External shower, located in garage Insulating mat for cab footwell, supplied loose Insulated partitioning curtain for cab, double-layered sewn Fabrics & Furniture finishes Furniture finish: Chiavenna Nut Fabric combination: Bolzano or Ventura Textile leather-/ fabric combination: Dalana Carpet: Laguna or Samona for cab and habitation area, supplied loose Living and bedroom + lighting 4 pillows Overhead lockers above rear beds instead of open shelves Sleeping system with cup-slatted bed frame for rear bed(s) Fitted sheets made to measure for rear beds individually adapted to mattress contours XXL bed, extra long mattress (+ 23 cm, incl. semi-high wardrobe (instead of floor-to-ceiling wardrobe) Kitchen Cooker- / oven combination Installation & Technology 6 kW gas warm air heating with warm water boiler and 1,800 W electric bar heater iNet Box (Control of warm air heating and roof AirCon via app as well as display of vehicle data) Gas bottle slide out External gas socket with shut-off valve Alarm system for cab-, habitation- as well as 2 garage doors / flaps Second habitation battery (95 Ah AGM) incl. additional 18 A charger HYMER Smart Battery System (50 Ah Lithium) incl. additional 18 A charger and battery computer HYMER Smart Battery System (150 Ah Lithium) incl. additional 18 A charger and battery computer Solar panel 2 x 90 W with MPPT controller and display Roof AirCon, 2,400 W Electric floor tempering in habitation area and central walkway Toilet vent Multimedia Multimedia SatNav System with 9" Touchscreen incl. motorhome software, DAB+, Apple Car Play, Google Android Auto as well as rear-view mirror function Second LED-TV in the bedroom, 22" TV with built-in speakers, DVD drive, DVB-T / C, DVB-S2, wiring as well as wall bracket Packages Style package for FIAT Exsis-t 580 Original Accessories (to be ordered directly from Hymer Original Parts) 12 months new vehicle warranty for new motorhomes with a technically permissible total mass of up to 4.5 to 24 months new vehicle warranty for new motorhomes with a technically permissible total mass of up to 4.5 to 36 months new vehicle warranty for new motorhomes with a technically permissible total mass of up to 4.5 to Sun protection mat Cab carpet Cot E-Bike Charger HYMER Bike Carrier for two bikes HYMER water filter clearliQ travel Sound system Dog bed incl. comfy cushion and leash TÜV / Brief TÜV approval / CoC
Exsis Pure package (Semi-Integrated)
The HYMER Exsis-t Pure comes with a comprehensive range of edition equipment and plenty of comfort for your journeys. If that's not enough, there are further equipment options for even more individuality.
